FG / FGX / G6E & XR6T Performance Packages
Stage 1
$1,582
Product Details
Custom 98 Octane Dyno Tune
K&N Airfilter & Airbox Modificaiton
Genuine Ford Spark Plugs
Fuel Filter
Drive in Drive out Including GST
Power Estimate:
98 Octane : 250 - 260rwkw
Stage 4
$10,552
Product Details
Custom Maxx Dyno Tune
Bosch 1000cc Injectors
Walbro 460 Intank Fuel Pump
Crow Race Valvesprings & Retainers
4” Turbo Side Race Intake
Battery Relocation Kit
Process West Stage 1 or 2 Intercooler kit
XForce Turboback 3.5" or 4” Exhaust
Genuine Ford Spark Plugs
Fuel Filter
Drive in Drive out Including GST
Power Estimate:
98 Octane: 300 - 310rwkw
E85 : 320 - 360rwkw
(This Package is Maxing out the Factory Turbocharger)
(Option of Process West 4” Race Airbox Kit Suit 3” Turbo Inlet & Battery Relocation Kit - Extra $690)
(Option of Garrett GTX3582 Supercore inc Flapper Mod, Garrett Actuator & GTX Bracket - Extra $3900
Will see roughly 400rwkw on 98 & E85)
(Headstuds are Recommended when using E85 Extra $760)
Stage 2
$3,142
Product Details
Custom Maxx Dyno Tune
Bosch 1000cc Injectors
Highflow Cat
K&N Airfilter & Airbox Modification
Genuine Ford Spark Plugs
Fuel Filter
Drive in Drive out Including GST
Power Estimate:
98 Octane: 260 - 280rwkw
Stage 4 -98 octane-
$14,452
Product Details
Custom Maxx Dyno Tune
Bosch 1000cc Injectors
Walbro 460 Intank Fuel Pump
Crow Race Valvesprings & Retainers
4” Turbo Side Race Intake
Garrett GTX3582 Supercore inc Flapper Mod, Garrett Actuator & GTX Bracket
Battery Relocation Kit
Process West Stage 1 or 2 Intercooler kit
XForce Turboback 3.5" or 4” Exhaust
Genuine Ford Spark Plugs
Fuel Filter
Drive in Drive out Including GST
Power Estimate:
98 Octane: 380 - 410 rwkw
Stage 3
$6,337
Product Details
Custom Maxx Dyno Tune
Bosch 1000cc Injectors
Walbro 460 Intank Fuel Pump
Highflow Cat
K&N Airfilter & Airbox Modification
Process West Stage 1 or 2 Intercooler Kit
Genuine Ford Spark Plugs
Fuel Filter
Drive in Drive out Including GST
Power Estimate :
98 Octane: 280 - 310rwkw
E85: 300 - 340rwkw
(Headstuds are recommended when using e85)
Stage 5
$19,102
Product Details
Custom 98 or E85 Dyno Tune
Bosch 1000cc injectors
Walbro 250 Intank Fuel Pump (Maxx Modified Fuel Cradle & Return Mod)
Process West Twin Walbro 460 Pump Surge Tank
Process West Surge Tank Fitting Kit
Process West Surge Tank Wiring Kit
Process West Stage 2 Intercooler Kit
Process West TB Elbow Upgrade (Alloy)
4” Turbo Side Race Air Intake
Battery Relocation Kit
Garrett Gen2 GTX3582 Supercore
Ported Rear Turbine Housing
38mm Flapper Mod
Garrett 12PSI Actuator
XForce Turboback 3.5” or 4” Exhaust
Crow Race Valve Springs & Retainers
Upgraded 12mm Head Studs
Genuine Ford Spark Plugs
Fuel Filter
Drive in Drive Out Including GST
Power Estimate:
98 Octane : 380 - 410rwkw
e85 : 480 - 500rwkw
Optional Extra’s
Process West 4” Race Airbox Kit Suit 4” Turbo Inlet & Battery Relocation Kit - Extra $690
Turbosmart 50mm External Wastegate Fabricated Off Rear Turbine Housing w/ Screamer Pipe
Extra $1050 while Turbo is being replaced
Upgrade of Garrett GTX3584RS 1000hp Bolt on Turbo - Extra $1540
”Maxx Drag Pack”
$9,490
Product Details
GJ Drivelines Pro-Series Tailshaft
Race Star Drag Wheels (17x4.5 & 15x8)
Mickey Thompson Tyres
Shockworks Coilovers - Drag/Street Setup
Superpro Rear Camber Adjustment
Guards Rolled/Pumped All Round - Phat Guard Rolling
Can be Optioned with Any Stage Package
